| 200KW WC系列柴油發電機組技術規格參數 | ||||
| 發電機組參數：/★Genset Specifications | ||||
| 1機組型號 Genset Model |
HQ200GF | 11穩態電壓調整率（％） Steady-State Voltage Regulation (%) |
≤±1 | |
| 2輸出功率 Output Power |
200KW | 12電壓波動率（％） Voltage Fluctuation Rate (%) |
≤±0.5 | |
| 3功率因數 Power Factor |
COSΦ=0.8(lagging) | 13瞬態電壓調整率（％） Transient Voltage Regulation Ratio (%) |
＋20～－15 | |
| 4輸出電壓 Output Voltage |
400V/230V | 14電壓穩定時間 Voltage Recovery Time (s) |
≤1 | |
| 5輸出電流 Output Current |
360A | 15穩態頻率調整率（％） Steady-State Frequency Regulation Ratio (%) |
≤±1 | |
| 6額定頻率 Rated Frequency |
50Hz | 16頻率波動率（％） Frequency Fluctuation Rate (%) |
≤±0.5 | |
| 7額定轉速 Rated RPM |
1500rpm | 17瞬態頻率調整率（％） Transient Frequency Regulation Ratio (%) |
＋10～－7 | |
| 8燃油牌號 Fuel Grade |
(Standard No. 0 / Ambient-Temperature Light Diesel Fuel)標準0#/常溫輕柴油 | 18頻率穩定時間 Frequency Recovery Time (s) |
≤3 | |
| 9外形尺寸 Dimension |
2900*890*1510（L×W×H mm）(Reference Only) | 19燃油消耗（100％負載） Fuel Consumption (100% Loaded) |
210g/kW·h | |
| 10機組重量Genset's Weight | 2500kg(Reference Only)參考 | 20噪聲（LP7m） Noise (LP7m) |
95dB（A） | |
| 柴油機參數：/★Diesel Engine Specifications: | ||||
| 1品牌/產地 Brand/Origin |
濰柴動力/濰坊 Weichai Power/Weifang | 9冷卻方式 Cooling Method |
Pressurized Water Cooling/封閉式水循環冷卻 | |
| 2油機型號 Diesel Engine Model |
WP10D238E200 | 10供油方式 Fuel Delivery System |
Direct Injection/直噴 | |
| 3柴油機額定功率 Diesel Engine Rated Power |
216kw | 11柴油機備用功率 Diesel Engine Standby Power |
238kw | |
| 4排量 Displacement |
9.726L | 12機油容量 Lubricating Oil Capacity |
24L | |
| 5氣缸數/缸體結構 Number of Cylinders/Cylinder Block Structure |
6/In-Line | 13調速方式 Governing System |
Electronic Governing/電子調速 | |
| 6缸徑行程 Bore × Stroke |
126×130 mm | 14進氣方式 Air Intake Method |
Turbocharged/渦輪增壓 | |
| 7壓縮比 Compression Ratio |
17：1 | 15過載能力 Overload Capacity |
110% | |
| 8啟動方式 Starting Method |
DC24V Electric Starting | 16轉 速 RPM |
1500rpm | |
| 發電機參數：/★Alternator Specifications | ||||
| 1品牌/產地 Brand/Origin |
Huaquan/Weifang | 6防護等級 Protection Class (IP Code) |
IP23 | |
| 2電機型號 Alternator Model |
HQF-XN200 | 7接線方式 Connection Method |
Three-Phase Four-Wire (3P4W)三相四線 | |
| 3額定功率 Rated Power |
200KW | 8調節方式 Voltage Regulation Type |
AVR自動電壓調節器 | |
| 4額定電壓 Rated Voltage |
400V/230V | 9輸出頻率 Output Frequency |
50Hz | |
| 5絕緣等級 Insulation Class |
H級 Class H | 10輸出因數 Output Power Factor |
COSΦ=0.8（滯后) (Lagging) | |
| 發電機組標準配置： | Generator Set Standard Configuration: | |||
| 1 直噴式內燃發動機（柴油）； | 1. Direct Injection Diesel Engine; | |||
| 2 交流同步發電機（單軸承）； | 2. AC Synchronous Alternator (Single Bearing); | |||
| 3 適合環境40℃－50℃散熱器水箱、皮帶驅動冷卻風扇、風扇安全護罩； | 3. Radiator Header Tank Rated for 40℃-50℃ Ambient, Belt-Driven Cooling Fan and Fan Safety Guard | |||
| 4 發電輸出空氣開關、標配控制屏； | 4. Generator Output Circuit Breaker, Standard Control Panel | |||
| 5 機組鋼制共用底座（含：機組減振橡膠墊）； | 5. Steel Common Base Frame (with Anti-Vibration Rubber Mounts) | |||
| 6 干式空氣過濾器、燃油過濾器、潤滑油過濾器、啟動馬達并配有自充電發電機； | 6. Dry-Type Air Filter, Fuel Filter, Lubrication Filter, Starter Motor with Self-Charging Generator. | |||
| 7 啟動蓄電池及蓄電池啟動連接電纜； | 7. Starting Battery with Connection Cables | |||
| 8 工業用9dB消音器及連接用標準件 | 8. Industrial 9dB(A) Silencer Kit (with Standrad Fittings) | |||
| 9 隨機資料：柴油機及發電機原廠技術文件、發電機組說明書、測試報告等。 | 9. Included Documentation: OEM Technical Documents, Operation Manual, Test Reports | |||
| 自選配件（費用另計）： | Optional Accessories (at extra cost) | |||
| 1 機油、柴油、水套、防冷凝加熱器 | 1. Engine Oil, Diesel Fuel, Coolant Jacket, and Anti-Codensation Heaters | |||
| 2 電瓶浮充電器 | 2. Battery Float Charger | |||
| 3 自保護、自啟動機組控制屏 | 3. Control Panel with Self-Protection and Auto-Start | |||
| 4 帶“三遙”功能機組控制屏 | 4. Control Panel with "Three-Remote" Functions (Monitoring/Control/Diagnosis) | |||
| ATS自動負載轉換屏 | ATS Automaitc Load Transfer Switch | |||
| 1 分體式日用燃油箱、一體式底座燃油箱 | 1. Split-Type Daily Fuel Tank, Integral Base-Mounted Fuel Tank | |||
| 2 防雨型機組（箱柜） | 2. Rain-Proof Enclosure (Canopy) | |||
| 3 靜音型機組（箱柜） | 3. Silent Enclosure (Canopy) | |||
| 4 移動拖車型電站（箱柜拖車） | 4. Mobile Generator with Trailer (Acoustic Enclosure Trailer) | |||
| 5 靜音型移動電站（箱柜拖車） | 5. Silent Mobile Generator with Trailer (Acoustic Enclosure Trailer) | |||
| 保修期： | Warranty: | |||
| 1 （國內）機組調試驗收合格后的12個月或累計運行1000小時；以先到期為準。 | 1. Warranty Period: 12 months after commissioning or 1,000 operating hours (whichever occurs first) | |||
| 2 由于產品質量問題實行免費維修或換件，終身有償服務！ | 2. Free repair/replacement for quality defects; paid lifetime maintenance service provided. | |||
| 3 易損件、常用件、人為損壞、疏忽保養等均不在保修范圍內 | 3. Exclusions: Wear parts, consumables, human-included damage, improper maintenance. | |||
| 4 如因原廠調整則以原廠保固條例執行！ | 4. If adjustments are made by the original manufacturer, the original manufacturer's warranty terms shall apply. | |||
| 付款方式及交貨期： | Payment Terms & Delivery Schedule | |||
| 支付寶、網銀轉帳、電匯、現金等付款方式，15個工作日內發貨。 | Payment Methods: Alipay, Online Banking Transfer, T/T, Cash; Delivery Period: Within 15 working days after payment confirmation | |||
| 執行標準： | Compliacne Standard: | |||
| 1 國際標準認證ISO9001：2000 | 1. ISO 9001:2000 | |||
| 2 行業執行標準GB/T2820.1997 | 2. GB/T280.1997 | |||
| 配送方式： | Delivery Method: | |||
| 上門自提、專車送貨、汽車配載等 | EXW/DAP/LTL/FOB/CIF | |||
